| Parameter | ST-30H | ST-30K |
| Ventilation mode | S/T, CPAP, S, T, PC, VAT | S/T, CPAP, S, T, PC, VAT, HFNC |
| Oxygen concentration | 21%~100%, (increment by 1%) | |
| Screen size | 5.7 inch color screen | |
| Waveform display | Pressure/flow | |
| IPAP | 4~30cm H20 | 4~40cm H20 |
| EPAP | 4~25cm H20 | |
| CPAP | 4~20cm H20 | |
| Target tidal volume | 20~2500mL | |
| Backup BPM | 1~60BPM | |
| Backup time | 0.2~4.0S | |
| Rise time | 1~6 level | |
| Ramp time | 0~60min (increment by 1 min) | |
| Ramp pressure | CPAP mode: 4~20cm H20 Other mode: 4~25cm H20 | |
| Pressure relief | 1~3 level | |
| Spontaneous Timin | 0.2~4.0S | |
| Spontaneous Timax | 0.2~4.0S | |
| I-Trigger setting | Auto, 1~3 level | |
| E-Trigger setting | Auto, 1~3 level | |
| Trigger lock | Off, 0.3~1.5S | |
| Flow of HFNC mode | N/A | 10~70L/min |
| Max flow | 210L/min | 300L/min |
| Max leak compensation | 90L/min | 120L/min |
| Method of pressure measure | The pressure testing tube is on mask side | |
| Alarms |
Apnea | Disconnection | Low minute volume| Low tidal volume | Power off | Over high pressure | Oxygen unavailable | Excessive oxygen pressure supply | Low oxygen pressure supply | Pressure tube off | Turbine dysfunction | Oxygen sensor failure | Air flow sensor failure | Low pressure | Low battery | Battery depleted |
|
| Apnea alarm range setting | 0S, 10S, 20S, 30S | |
| Disconnection alarm range setting | 0S, 15S, 60S | |
| Real-time monitoring data | Pressure | Ventilation per min | Respiratory rate | | |
| Current leakage | Current volume | Trigger method | ||
| Max flow |
Screen lock | Display brightness | Flow | Pressure | Waveform |
Screen lock | Display brightness | Flow | |
| Pressure | Waveform | Event summary | ||
| Backup battery | 8 hours | |
| Heating range | 40~70 Celius | |
| Adjustment | 1~9 level | |
