6.44 MP Automatic Mini Gel Documentation Imaging Analysis System
Band nameICLEAR
Model No.CHL-S2
CertificateISO CE
Add to Favorites
Quick Details
One-key operation, automatic retractable sample stage, to ensure the airtightness of the darkroom environment of the chassis
Small size, built-in touch screen, no need to connect additional computer
16-bit scientific research-grade high-sensitivity digital camera with pixel binning function and a variety of color casings to choose from
Packaging & Delivery
Product Description
6.44 MP Automatic Mini Gel Documentation Imaging Analysis System
CHL-S2
S2 for a short gel imaging system, mainly used for the analysis and research of electrophoresis gel images, hybridization membranes, etc. A high-resolution and high-sensitivity camera guarantees no loss of bands in low light. Fully automatic computer control, highly programmed, easy to operate, convenient and practical. The full-featured gel image analysis software helps researchers obtain electrophoresis photos and analysis results accurately and quickly. Help the majority of researchers engaged in molecular biology and hospital clinical to get rid of the tedious operation process and improve work efficiency.
Features
No need for any focusing operation, one-click to obtain ideal experimental results
With two USB3.0 interfaces, it can expand the functions of WIFI data transmission, mouse or printer, etc.
One-key operation, automatic retractable sample stage, to ensure the airtightness of the darkroom environment of the chassis
Small size, built-in touch screen, no need to connect additional computer
16-bit scientific research-grade high-sensitivity digital camera with pixel binning function and a variety of color casings to choose from
|
Model |
CHL-S2 |
|
Shooting area |
170* 130mm |
|
Camera |
16-bit scientific-grade digital camera |
|
L ens |
Fixed focus; F1.4 |
|
Pixels |
6.44 megapixel (3096*2080) |
|
Pixel binning |
1*1 and 2*2 optional |
|
Tablet computer |
10.1-inch touch screen; max resolution: 1920* 1200 |
|
Sample tray |
Power-driven |
|
Blue light transmission wavelength |
470nm |
|
Software |
Manual exposure, auto exposure and multi-frame shooting optional |
|
Data interface |
USB3.0*2 |
|
Power input |
100~240VAC, 50~60Hz |
|
Dimension (W*D*H) |
286*355*321mm |
|
Net weight |
12 kg |
Application
Nucleic acid amplification testing:
Various fluorescent dyes such as Ethidium Bromide, SYBR™ Gold, SYBR™ Green, SYBR™ Safe, GelStar™, Texas Red, and Fluorescein, labeled DNA/RNA detection.
Protein detection:
Coomassie Brilliant Blue Glue, Silver Stain Glue, and Fluorescent Dyes such as Sypro™Red, Sypro™Orange, Pro-Q Diamond, Deep Purple Labeling Glue/Membrane/Chip, etc.
other apps:
Various hybridization membranes, protein transfer membranes, culture dish colony counting, microtiter plates, TLC plates, etc.
