PRODUCT DETAILS

High-Quality Multi-Functional Portable Container House for Quarantine Isolation Container

Band nameICLEAR

Model No.CHH-33

CertificateISO CE

Add to Favorites

Quick Details

Container Frame

Q355B low carbon structural steel with hot dip galvanizing 100g/m2. After welding, the integral frameuses electrostatic powder spraying(100um).

Roof Panel:

60mm PU foaming roof,PU density:45kg/m3. With two-side colored steel sheet, Aluminum Zincgalvanized 50g/m2+ PE baking finish 15/5um.

Upper steel sheet is 0.45mm, color is optional, Lower steel sheet 0.40mm, color is milky white.Column 2.3mm thick Q355B steel,210x150mm

Wall Panel:

50mm EPS sandwich panel, EPS density:12kg/m3. Material option is PU (density 40kg/m3) , rock wool( density 120kg/m3).

Colored steel sheet is 0.40m. Panel's outside is color-optional with ribs, inside is milky white. The steel sheet surface is Aluminum Zinc galvanized 50g/m2+ PE baking finish 15/5um.

Floor : 1.8mmPVC floor(The color of PVC floor is blue spot/wood grain)+18mm cement fiber board

Door : 960x2080mm Steel Door

Window : 980x1150mm PVC single glass sliding window (with screen window inside).

Option: Aluminum alloy window; adding wind-proof rolling shutter

LED ceiling lamp: 2pcs x 30w LED ceiling lamps,L=1200mm

Switch: 1pc xsingle control switch (national standard rocker single control)

Socket: 2pcsx10A sockets,1pc x32A 3-level outdoor waterproof inlet socket.

Option: adding airconditioner socket

Distribution box: 1pcx 8-circuit power distribution box,built-in 1pc x4P32A total circuit breaker (withleakage protection),1pcx 1P lighting circuit, 1pc x1P socket circuit

This container house does not contain bathroom part

Packaging & Delivery

5980mm * 2438mm * 2591mm

Product Description

High-Quality Multi-Functional Portable Container House for Quarantine Isolation Container
CHH-33

In order to meet different requirements, develops an economical container house, standard size is 5980mm*2438mm*2591mm. It adopts welded integrated frame with PU foaming insulated roof and all-welded integrated chassis. Based on traditional container, its profile material, drainage system and power system have great advantage, which lower the installation difficulty and save installation time. adopts fully automatic production line such as robot welding, which can reduce the manual error and improve the uniformity of the weld seam. This efficient way can greatly accelerate the production speed, and provide strong technical support for the "seven-day delivery" of the standard container.
Container uses integrated welding foaming roof ,PU density:45kg/sqm. Welding by robot reduces the manual error, the weld seam can be good-looking and uniform without shortage of welding; The overall spray line and roof foaming equipment can make more standardized products and double accelerate the production speed.
Wall is combined of 14pcs wall panels. Standard is 50mmEPS sandwich panel. EPS density is 12kg/m3. Door, window, switch, socket are all pre-assembled on the wall panel. There are prefabricated quick-plug on the wall panel, the panel position can be moved for random combination during installation. Door:960x2080mm, steel door Window:980x1150mm PVC single glass sliding window (with insect-proof screen). Window and door are pre-assembled on wall panels , very convenient for installation. Position can be randomly moved.
Container Frame
Q355B low carbon structural steel with hot dip galvanizing 100g/m2. After welding, the integral frameuses electrostatic powder spraying(100um).
Roof Panel:
60mm PU foaming roof,PU density:45kg/m3. With two-side colored steel sheet, Aluminum Zincgalvanized 50g/m2+ PE baking finish 15/5um.
Upper steel sheet is 0.45mm, color is optional, Lower steel sheet 0.40mm, color is milky white.Column 2.3mm thick Q355B steel,210x150mm
Wall Panel:
50mm EPS sandwich panel, EPS density:12kg/m3. Material option is PU (density 40kg/m3) , rock wool( density 120kg/m3).
Colored steel sheet is 0.40m. Panel's outside is color-optional with ribs, inside is milky white. The steel sheet surface is Aluminum Zinc galvanized 50g/m2+ PE baking finish 15/5um.
Floor : 1.8mmPVC floor(The color of PVC floor is blue spot/wood grain)+18mm cement fiber board
Door : 960x2080mm Steel Door
Window : 980x1150mm PVC single glass sliding window (with screen window inside).
Option: Aluminum alloy window; adding wind-proof rolling shutter
Electricty
LED ceiling lamp: 2pcs x 30w LED ceiling lamps,L=1200mm
Switch: 1pc xsingle control switch (national standard rocker single control)
Socket: 2pcsx10A sockets,1pc x32A 3-level outdoor waterproof inlet socket.
Option: adding airconditioner socket
Distribution box: 1pcx 8-circuit power distribution box,built-in 1pc x4P32A total circuit breaker (withleakage protection),1pcx 1P lighting circuit, 1pc x1P socket circuit
This container house does not contain bathroom part
