1) Our dual-layer co-extrusion tubes use TOTM (DEHP free) as plasticizer The inner layer doesn* t contain colorant. The purple color of the outer layer can prevent misusing with IV sets.
2) Compatible with various feeding pumps and liquid nutrition containers.
3) Its internationally universal stepped connector can be used for various nasogastric feeding tubes. Its stepped design can prevent feeding tubes from accidently fitting into IV sets.
4) Its Y-shaped connector is very convenient for feeding medicine and flushing tubes.
5) We have different models and specifications to meet different clinic needs.
DEHP Free Medical Enteral Nutrition Feeding Pump
CHO-5021A
Features
1) Our dual-layer co-extrusion tubes use TOTM (DEHP free) as plasticizer The inner layer doesn* t contain colorant. The purple color of the outer layer can prevent misusing with IV sets.
2) Compatible with various feeding pumps and liquid nutrition containers.
3) Its internationally universal stepped connector can be used for various nasogastric feeding tubes. Its stepped design can prevent feeding tubes from accidently fitting into IV sets.
4) Its Y-shaped connector is very convenient for feeding medicine and flushing tubes.
5) We have different models and specifications to meet different clinic needs.
Specifications:
Pumping Mechanism:Curvilinear peristaltic
Enteral Feeding Set:Standard enteral feeding set with silicon tube
Flow Rate:1-2000 rrt/h (in 1,5,10 ml/h increments)
Purg,Bolus:Purge when pump stops, bolus when pump starts, adjustable rate at 600*2000 ml/h (In 1,5,10 ml/h Increments)
Accuracy:±5%
VTBI:1-9999 ml (in 1,5,10 ml increments)
Infusion Mod:mVh
Withdraw:600-2000 ml/h (In 1,5,10 ml/h increments)
Cleaning:600-2000 rri/h (In 1,5,10 ml/h increments)
Alarms:Occlusion, airmine, door open, end program, low battery, end battery, AC power offt motor malfunction, system malfunction, reminder alarm, tube dislocation
Additional Futures:Real4ime infused volume, automatic power switching, mute ke purge, bolus, system memory histoiy log, withdraw, cteanlng
Occlusion Sensttvty:High, medium, low
History Log:30 days
Alr-in-line Detection:Ultrasonic detector
Wireless Management:Optional
FkiId Warmer:Optional (3040.in 11 incremente, over temperature alarm)
Vehicle Power (Ambulance):12V
Power Supply, AC:110/230 V, 50/60 Hz, 45 S
Battery:10.8 V. rechargeaUe
Battery Life:8 hours at 100 ml/h
Woriclng Temperature:10-30X
Relative Humidity:30-75%
Atmospheric Pressure:860-1060 hpa
Size:150(L)*120(W)*60(H) mm
Wei0ht:1.5 kg
Safety Classificatioffi:Qass n.typeCF
Fluid Ingress Protection:IPX5
Application
Our products can be used for nasogastric feeding tubes, nasogastric stomach tubes, enteral nutrition catheter and
feeding pumps.
