Canon EOS Ultra HR Mydriatic Fundus Camera

CHE-C3000

• Image acquisition system uses Canon Eos.18 million high pixel.High resolution imaging.

• The minimum diameter of shooting pupil just 3.3mm.

• Double dot auxiliary focus makes the operation simple and intuitive, easy to get start.

• Powerful image processing functions, it can measure, calculate, note, contrast, and other functions, and convenient case


• Image acquisition system
  Acquisition   mode		Non-mydriatic/mydriatic   color image Anterior   segment image FFA
  Field   angle		42°（non-mydriatic）/50°
  Working   distance		42mm
  Pupil   diameter		≥3.3mm
  Image   acquisition		Canon   EOS600D，External SLR system
  Resolution		18 megapixels
  Compensation   for ametropia		±20D
  Focus-assist   way		Double   spot focus-assist lamp
  Image   workstation		Reticam   v1.1
  Dimension		760mm（length）×680mm（width）×740mm（height）
  Weight		20.3kg
  Power		220V/50HZ/5A
  Computer   system/accessories
  Operating   system	Windows   7
  Hard   disk	500G
  Memory	2G
  CPU	Intel   Dual Core Processor
  Interfaces	USB ports、Network   connectors
  Accessories	22.6”   wide-screen LCD monitor、color   inkjet printer、mouse、keyboard
