Feature
Apochromatic optical balance technology is used in the optical design to provide good binocular fusion, strong stereoscopic sense and good color restoration.
Space Balancing System is used in the instrument to make the microscope lens and arm to push and pull in any direction with ease.
The module design is used in electrical design to provide the instrument with fault self-diagnosis function and simple maintenance.
Good extensibility to add teaching microscope, image device and image system.

Specifications

Eyepiece Magnifications	12.5X18B
Objective Lens	f=200
Working Distance	170mm
Magnification for Main Microscope	4.6X~27X motorized and manual control continuous magnification
Magnification for Assistant Microscope	6X,10X,16X
Diameter of Field	4646+46mm~8.58.588.58mm
Diopter Adjustment	±7D
Pupil Distance	50mm ~ 75mm (main microscope is 45mm ~ 80mm)
Maximal Resolution	119 LP/mm
Focusing Range for Assistant Microscope	≥30mm
Illumination Source	12V/100W, cold reflection halogen lamp for medical use
Illumination Type	6°+0°coaxial illumination of the cold light source, 26°oblique illumination
Coaxial Illumination	≥80000lx,1~9level,panel operated
Oblique Illumination	≥60000lx,1~9level, panel operated
Reaching Radius of Arm	1230mm
Adjustable Vertical Range	880mm~1420mm
Fine Focusing Speed and Range	≤2mm/s,≥50mm
Speed for X/Y and Range	≤2mm/s,50mmX50mm
Input Voltage	AC220V±22V/50Hz±1Hz, AC110V±11V/60Hz±1Hz
Power	170VA
Fuse	AC250V T4.04.0444.0000A ,AC1250V T8.0588.0A
Electrical Safety Standard	Executive standard:GB9706.1-2007,Class I
Packing Volume	0.756m3,5cartons
Total Weight	215kg
