PRODUCT DETAILS

Ophthalmic Equipment Eye Surgical Laser Photocoagulator

Band nameICLEAR

Model No.CHE-MD960

CertificateIOS CE

Add to Favorites

Quick Details

Wavelength: 532nm
Output power: 50mW ~ 1800mW step adjustable
Pulse Width: 0.01s - 3s
Pulse interval: 0.05% - 1s, or a single pulse (SP)

Packaging & Delivery

30cm*28*cm*14cm
23KG

Product Description

Ophthalmic Equipment Eye Surgical Laser Photocoagulator
CHE-MD960

1. Compact
Compact and portable design for advanced solid-state-laser technology Touch-screen operations for easier use.

2. Precise
Continuously zoomed and precise laser spot size
Homogeneous photocoagulation spot on the retina
Stable output but no power degeneration for closed-loop power control system

3. Safe
Minimized power density on the cornea, Maximum protection while maintaining clear field view

4. Adaptable
Detachable delivery system, compatible with a range of slit-lamp microscopes.

Treatment Beam
Type:	Diode-pumped frequency-doubled solid-state laser
Wavelength:	532nm Green True CW
Power Output:	50-1200mW,adjustable
Pulse Duration:	0.01s-3s,adjustable
Pulse Interval:	0.05s-1s,adjustable
Aiming Beam:
Type:	Laser diode
Wavelength:	630-680nm
Power Output:	<1.0mW,adjustable
Cooling:	Air Cooled, Thermoelectric Cooler System
Laser Delivery Unit:	Slit Lamp Adapter
Slit Lamp Delivery:	Haag Streit slit lamp
Spot Size:	Continuously adjustable from 50 to 500 microns
Power:	100-240VAC
Size:	30cm28cm*14cm
