PRODUCT DETAILS
Bench-top electric low-speed centrifuge
Band nameICLEAR
Model No.CHL-C8 Series
CertificateISO CE
Add to Favorites
Quick Details
Working power: 220V 50HZ
The highest speed: 4000r/min
The maximum relative centrifugal force: 1435-2325×g
Working capacity: 6×20ml /12×20ml
Packaging & Delivery
32*30*28cm
N.W. 2.1KG G.W.3.6KG
Product Description
Bench-top electric low-speed centrifuge
CHL-C8 Series
Bench-top electric (low-speed) centrifuges are used for qualitative analysis in hospital laboratories, clinics, biochemical laboratories, and bio-product laboratories for plasma, serum, urea, and vaccine manufacturing.
Technical Parameters:
Working power: 220V 50HZ
The highest speed: 4000r/min
The maximum relative centrifugal force: 1435-2325×g
Working capacity: 6×20ml /12×20ml
Technical Specifications:
|
model |
Maximum speed |
Speed regulation |
Centrifugal force |
Working capacity |
Timing |
|
CHL-C8 |
4000r/min |
Stepless speed regulation |
1435×g |
6×20ml |
|
|
CHL-C8D |
4000r/min |
Stepless speed regulation |
1435×g |
6×20ml |
0-60min |
|
CHL-C81 |
4000r/min |
Stepless speed regulation |
1795×g |
6×20ml |
0-60min |
|
CHL-C82 |
4000r/min |
Stepless speed regulation |
2325×g |
12×20ml |
0-60min |
Instructions for use:
The workbench of the centrifuge should be balanced and fixed. The workroom should be clean, dry and well ventilated. The ambient temperature should be 5~PREFIX=ST132°C. Before turning on the centrifuge, wipe the rotor clean, place the test tube with the same weight, close the centrifuge cover, adjust the speed control knob, and increase the speed to the required speed (high speed start is forbidden).
Maintenance:
After each use, turn off the power, wipe the inner cavity and rotating head, and cover the centrifugal cover. After the carbon brush of the motor is used for 3,000 hours, it should be replaced in time to avoid wearing the commutator. After long-term use of the centrifuge, natural wear is a normal phenomenon. After one year of use, if there is a failure or difficulty, the company will continue to provide quality services and assist it.
