Sony Ultrasound Color Video Printer

Band nameSony
Model No.UP-D898MD
CertificateCE ISO
Add to Favorites

Quick Details

*High Speed output-16 seconds for S-size prints
*Equipped with high-performance DSP engine and 423 dpi thermal head
*Vivid, smear-free gradation

Packaging & Delivery

3kg

Product Description

Sony Ultrasound Color Video Printer
UP-D898MD


High-speed printing;
High stability;
High-density print head and thermal paper matched to reproduce detailed images;
High precision and appropriate size of print options;
Front-button easy to operation;
Mitsubishi unique large area, easy to read LED digital display;
A variety of image size can be easily set by user;
Widely used in medical diagnosis.



Specifications:
Printing Method: Direct thermal printing;
Thermal Head: Thin film thermal head(1280dots);
Gradations: True 256 gray balance;
Resolution: 325 DPI;
Printed Picture Size: 4"(W) x 12 5/8"(H);
Effective Pixels: EIA 1280 dot x 508 lines; CCIR: 1280 dot x 608 lines
Memory: 10 frames
Input/Output: Video In: BNC, CCIR or EIA composite video signal, 1.0
Vp-p, 75 ohms/ high impedance selectable
Video Out: BNC, Loop-through or E to E selectable
Print Speed: Approximately 3.3seconds (High Speed Mode)
Remote Terminal: Stereo Mini-jack
Power Requirements: 100V to 240V, 50/60 Hz, 1.5A to 0.8A (Worldwide)
Dimensions (WHD): 154× 89.5× 256mm(W× H× D)
Weight: 2.8kg
Safety Standards: UL60950-1 Listed CSA C22.2 No. 60950-1 UL60601-1 Listed CSA No. 60601-1
Supplied Accessories: AC Power Cord
Operation Manual (CD ROM)
Thermal Head Cleaning Sheet
BNC Video Connecting Cable
