Magnetic Bead Extraction:
Process samples up to 1ml, 3ml or 5ml
The AP series can process up to 32 samples per run when the working volume is up to 1 ml. With the ability to change the instrument configuration, the customers can elevate the sample processing volume up to 3ml or 5ml to obtain higher yields of the purified product, and a throughput of up to 20 samples.
| Throughput | 1~32 | 1~20 | 1~20 |
| Process volume | 50~1000ul | 50~5000ul | 50~3000ul |
| Collection efficiency | >95% | >95% | >95% |
| Magnetic rod number | 32 | 20 | 20 |
| Purification accuracy | 100 copy sample | 100 copy sample | 100 copy sample |
| positive rate>95% | positive rate>95% | positive rate>95% | |
| Stability | CV<5% | CV<5% | CV<5% |
| Plate types | 96 Deepwell plate | 5ml tube strip | 3ml tube strip |
| Heating for lysis tube | ~120°C | ~120°C | ~120°C |
| Heating for elution tube | ~120°C | ~120°C | ~120°C |
| Operation | 7-inch color touch screen | 7-inch color touch screen | 7-inch color touch screen |
| Extraction steps | Lysis, Sample binding, | Lysis, Sample binding, | Lysis, Sample binding, |
| Washing and elution | Washing and elution | Washing and elution | |
| Storage Capacity | more than 100 programs | more than 100 programs | more than 100 programs |
| Protocol Management | Create, edit, delete, | Create, edit, delete, | Create, edit, delete, |
| protocol mode | protocol mode | protocol mode | |
| Pollution Control | UV light | UV light | UV light |
| Lighting | Yes | Yes | Yes |
| Extension interface | 4 standard USB port, built-in SD card | 4 standard USB port, built-in SD card | 4 standard USB port, built-in SD card |
| Exhaust | Fan | Fan | Fan |
| Power Supply | 450W | 450W | 450W |
| Dimensions | 400×520×450mm | 400×520×450mm | 400×520×450mm |
| Weight | 28Kg | 28Kg | 28Kg |
