PRODUCT DETAILS

12 Slides Programmable FISH or ISH Hybridization System

Band nameICLEAR

Model No.CHL-TDH500

CertificateISO CE

Add to Favorites

Quick Details

1. Touch screen allows for easy-to-read, program and use
2. it can run In-situ PCR experiments
3. Possibility to export cycles data via USB memory
4. Four operation modes: denaturation/hybridization, hybridization fixed temperature, custom, In-situ PCR
5. Can be used as a fixed temperature slide warmer
6. Rapid temperature warm-up and accuracy of ±1°C
7. Superior temperature uniformity across all slide positions
8. Perfect humidity control system

Packaging & Delivery

225×420×143mm 5.8kg

Product Description

12 Slides Programmable FISH or ISH Hybridization System
CHL-TDH500

Programmable system and humidifying that automates the steps in a slide-based FISH procedure and provides
walk-away convenience for clinical and research personnel. Up to 12 slides can be easily added or removed
with one hand. Two-side heating of slides allows for achieving exact correspondence of the set and actual
temperature and maintaining uniform temperature across all slide positions.
To build upon the innovative design, CHL-TDH500 is ideally suited for the needs of cytogenetic laboratories to provide a good instrument.

Features
1. Touch screen allows for easy-to-read, program and use
2. it can run In-situ PCR experiments
3. Possibility to export cycles data via USB memory
4. Four operation modes: denaturation/hybridization, hybridization fixed temperature, custom, In-situ PCR
5. Can be used as a fixed temperature slide warmer
6. Rapid temperature warm-up and accuracy of ±1°C
7. Superior temperature uniformity across all slide positions
8. Perfect humidity control system

Specifications

MODEL	CHL-TDH500
Temperature Control Range	RT+5°C~99.9°C
Temperature Accuracy	±1°C
Temperature Uniformity	±1°C
Processing Timer	1min~99h59min or 1sec~99min59sec
Temp. Display Accuracy	±0.1°C
Heating Time ( 37°C to 95°C )	≤3min
Cooling Time(95°C to 45°C)	≤7min
Temperature Control Programmable	30°C ~100°C
Operation mode	Denaturation/Hybridization, Hybridization fixed temperature, Custom and In-situ PCR
Capacity	12 Slides
Display	Touch Screen
Overall Dimensions	225×420×143mm (L x D x H)mm 5.8kg
