Fully-automated solution
HPLC method
No sample pre-treatment needed
Less than 5minutes per test
Two sampling modes: whole blood and prediluted mode
Original reagents, QC and calibrators
HPLC Automatic Hemoglobin HbA1c Analyzer
CHL-H2000
Introduction
The CHL-H2000 HbA1c analyzer is intended for the percent determination of hemoglobin A1c in human whole blood using HPLC method.
Hemoglobin A1c is tested for diabetes control and treatment assessment.
The blood samples are automatically diluted on the analyzer and injected into the micro-column installed inside.
The analyzer delivers a programmed buffer gradient of increasing ionic strength to the micro-column, where the hemoglobins are separated based on their ionic interactions with the resin material in the micro-column.
The separated hemoglobins then pass through the flow cell of the filter photometer, where changes in the absorbance at 415 nm are measured.
Advantages:
Fully-automated solution
HPLC method
No sample pre-treatment needed
Less than 5minutes per test
Two sampling modes: whole blood and prediluted mode
Original reagents, QC and calibrators
Features:
Fully automated system
Testing Speed: 5minutes/test
Measurement Range: 3%-18%
Colorimetric Wave-length: 415nm
Precision: CV<=3%
Autoloader: Optional for automatic sample stirring. Maximum 50 samples
Sample pre-heating eliminates the interference of unstable hemoglobin
Robot arm mixes every blood sample thoroughly
Real Walkaway System
Fully automated system minimizes manual operating
Continuous sample loading and processing brings maximum convenience
Intelligent daily maintenance keeps the analyzer in best condition
User Friendly Interface
Color touch screen operation
One touch to do all tests
Zero Maintenance
Intelligent error diagnosis program
