PRODUCT DETAILS

small 48/96 well Semi-automatic Elisa analyzer

Band nameICLEAR
Model No.CHL-R31
CertificateISO CE
Add to Favorites

Quick Details

Plate type: 48-/96-well plate or strip
Cleaning head: 8/12 wash heads
Strip washing: 1-12 wash strip
Soaking time: 0-48 hours
vibration plate features: vibration plate speed 1-5 grade,time 0-225 seconds

Packaging & Delivery

500mm×450mm×230mm  8KG

Product Description

small 48/96 well Semi-automatic Elisa analyzer

CHL-R31


Main technical parameter

Plate type

48-/96-well plate or strip

Cleaning head

8/12 wash heads

Strip washing

1-12 wash strip

Soaking time

0-48 hours

vibration plate features

vibration plate speed 1-5 grade,time 0-225 seconds

Residue volume

≤1uL

Allocation accuracy

≤±3% at 300uL

Washing channels

1-4 (standard one -channel,2,3 or4- channels are optional)

Washing lotion volume

50UL-2000UL(12-pin) or 50UL-3000UL (8-pin)

Interface

USB printer interface ,RS232

power supply

AC220V±22V,50±1Hz

size

445mm×362mm×198mm

Working environment

Temperature:5°C-40 °C



Humidity:≤85%

Storage environment

Temperature:'-20°C-55 °C



Humidity:≤95%



1.Operation menu in english and  Large-Screen liquid crystal display.

2.have the features of center and two points pipettes,full pipettes,low amount of residue

3.have the vibration plate (Grade 5) and soaking (48hours) capabilities to meet the requirments of different experiments

4.Have program storage ,retrieval ,delete function ,100 groups of user customized programes can be stored.

5.Have the plate position (6 parameters) adjustment functions, suitable for a variety os different specifications of the Elisa plate (flat-bottomed ,U-type and V-type).can store 10 kinds of plate-type positional parameters.

6.Have the pipeline flusing ,pressure regulator ,liquid level alarm and many other auxiliary functions,are more conducive to routine operational use .
