9600P adopts Ferrotec specially-made Peltier advanced fiber optic technology new global wide-range power supply the unique patented block dissipation technology and bottom detection mode which provides better heating/cooling rate temperature accuracy uniformity and stability. 9600P has up to 96 sample capacity and fast speed of dual-color scanning and the design of 5 channel detection also covers the whole fluorescence detection wavelength.Newly-designed automatic hot-lid without manual operation ensures constant pressure for various tube heights. This auto hot-lid mode could be easily integrated into various automatic systems. Its Windows tablet computer and new touch screen brings excellent operating experience.Newly-improved 9600P Real-Time PCR detection system can satisfy various clients' requirement either for research or clinical use.

410*386*352mm
25kg

DNA Real-Time PCR detection system

---

CHL-96A


New Industry Design for Powerful Core

---

Long-life 72 series thermo module (Ferrotec patent), life is increased by 3 times
Multiple tube adaptation
Patent high efficiency heat sink


New design automatic hot-lid, automatic station adaptation
Tube height automatic adjustment function
Hot-lid sealing enhancement, avoid evaporation
Open hot-lid manually if power off


Patent bottom fluorescence detection
New generation PMT, sensitivity +20%
Fluorescence detection range increase 100%
Eliminate interference of fluorescence
5 channels fluorescence solution

PK Advantages

---

Specifications

---



Detected Fluorescence	F1:FAMSYBR Green Ⅰ; F2:VICHEXTETJOECY3TAMRA; F3:ROXTEXAS-RAD F4:CY5Quasar-670; F5:CY5.5Quasar-705;
Block Temp.Range	4 ~105 ℃ ( Minimun Increment  :  0.1 ℃ ) SOAK Low Temp.Consercation Function
Temp.Control Mode	BLOCK/Tube Simulation Mode (Automatic Control based On Sample Volume )
Gradient Temp.Range	1 ~36 ℃
Hot-lid Temp.Range	30 ~110 ℃ (Adjustable default 105 ℃ Automatic Hot-lid )
PC Configuration	Memory:512M     Hard Disk:10GB    CPU:Pentium® 4    Virtual Memory:≥1000MB
Operation System	Microsoft  :  Windows XP/Windows vista/Windows 7/Windows 8 Software  :  Excel2000/2002/2003/2007/2012
Power Supply	100-240V ~ 50/60Hz   600W
Dimension ( L×W×H )	410mm×386mm×352mm
socket	USB Adapter  Bluetooth Adapter
Authentication	Ferrotec Pelitier / CE/Met / RoHS2 / PICC product quality liability insurance
